1. In the process of processing products, when the height direction and scale change greatly, do not adjust the depth of the wear tool repair, first check whether there is aluminum slag inside the tool handle and spindle, and then add the wear tool repair after confirming that there is no slag.
2. The thickness of processing products is different when clamping with pliers. The outside scale is thinner and the inside scale is thicker. This is the external clamp clamp to push the product up, pay attention to whether the moving parts of the clamp are too loose, after locking it can deal with the problem of product thickness difference.
3, CNC machining deep hole precision requirements when the simple taper, especially in the hole deep loading tool is long is difficult to ensure the next to, can be opened to leave a few rough and then with boring tool processing.
4. When processing products with higher surface finish requirements, it is difficult to satisfy customer requirements with rough knife pattern. At this time, the large surface can be installed with PCD knife, and the small surface can be customized with PCD flat knife to improve the surface finish.
5, 304 stainless steel material, it is very simple to wear the tool when processing, cold cutting liquid can be changed to oil cold, oil cold can improve the service life of the tool. Together in processing aluminum tapping diameter is small, tapping simple break can also be oil cold cutting.
6. Corner knife
When a product corner knife is found, the first analysis of the size of the product corner, the use of less than the corner R Angle of the tool. It can also be handled by reducing the spindle speed.
7, chamfer has burr
When the product chamfer is found to have burr, the first check whether the tool is worn, if the tool is intact, and then check the chamfer depth and range of size, generally these two aspects can deal with chamfer burr problem.
8. Splint injury
SZBJ is a professional machining manufacturer, owns3-5 axis CNC machining center,CNC lathes, CNC Milling machines, CNC turning and milling composite machines, computer gong processing, high-speed machines,Drilling machines, internal grinding machines.Cylindrical grinder machines, turning-lathe machines, CNC wire-cut machines,CNC Bending Machines etc.
CNC machining (computer gong processing) can apply for autoparts parts machining, automation equipment parts processing, OEM robotic structural components,
airplane/aircraft part, custom household appliances parts , medical system producing , beauty device development, uav parts manufacturing
